STRUDL-X History

Presentation & History

STRUDL-X is a general Finite Element software with specific extensions for the Offshore Oil & Gas and Wind domains, including Environmental Actions, Code Checking and Fatigue Analysis.

STRUDL-X is developed and maintained at STRUSIM since 2004 by a team of Senior Structural Engineers, involved in numerous R&D projects, to meet the needs of the industry.

STRUDL-X is the successor of NSO (New Strudl Offshore) derived from BV-STRUDL, developed by Bureau Veritas / C. Briwand from the IBM version of STRUDL, derived itself from the original Massachusetts Institute of Technology (MIT)’s STRUDL-II program initiated in the 70’s.

Feature Overview

Main Features

Beam and Finite Element models up to 2 million nodes

High performance static & dynamic solvers

Linear & Nonlinear analyses including initial states and P-Delta effects

Fatigue damage computation, deterministic and spectral methods. Automatic SCF computation (Efthymiou)

Multilevel substructures and superelements, non-structural components

Database with full save and restore facilities

“Exact” beam elements with concentrated or distributed local loads and detailed results in any section

Extensive 2D and 3D Finite Element library

Gaps, contacts, member end flexibilities, plastic hinges and other nonlinear connectors

Code Checks according to applicable rules and standards (API, AISC, ISO, EC3, NORSOK, DNV-GL, BV…)

Environmental loads, Piles & soil modeling

Detailed analyses of tubular joints

Selective, formatted (HTML, XML, CSV…) results outputs

Interfaces with external software (SACS, FEMAP, ISYMOST…)

Dedicated Graphical User Interface

Readable structured input files with efficient management of units. Built-in programming language for parametric generation of commands.
